Konica Minolta EP1050 [5/131] Chapter 4 auxiliary functions 51
![Konica Minolta EP1050 [5/131] Chapter 4 auxiliary functions 51](/views2/1122092/page5/bg5.png)
Chapter 4 Auxiliary Functions 51
1. Checking the Total Number of Copies Mode
52
2. Auxiliary Toner Replenishing Mode
(Increasing the Image Density) 54
3. Drum Dehumidify Function 55
4. User’s Choice 56
Chapter 5 When an Indicator
Lights Up 67
(Replenishing Supplies, Clearing Misfeeds,
and Correcting a Closure Failure)
1. Quick Reference for Indicator Lights 68
2. Detailed Instructions for Indicator Lights
Add Toner Indicator 70
Add Paper Indicator 72
I.U. Service Life Indicator 76
Closure Failure Indicator 85
Misfeed Indicator
• Misfeed Indicator and Monitor Display 86
• Misfeed Clearing Procedures
: Copier EP1050 87
: Automatic Document Feeder AF-3 90
: Sorter S-104 92
Call-Tech.-Rep. Indicator 93
Contents
v
