Zoom Ratio Table (Original Size to Copy Paper Size)
Metric Size
Original Size
Copy
Paper Size
Zoom Ratio
A3 A4 70%
297 × 420 mm
11-3/4" × 16-1/2"
A5 50%
B4 86%
B5 61%
A4 A5 70%
210 × 297 mm
8-1/4" × 11-3/4"
A6 50%
B5 86%
B6 61%
A3 141%
B4 122%
A5 A6 70%
148
× 210mm
5-3/4" × 8-1/4"
B6 86%
A4 141%
A3 200%
B4 173%
B5 122%
A6 A4 200%
105 × 148 mm
4-1/4" × 5-3/4"
A5 141%
B5 173%
B6 122%
B4 A4 81%
257 × 364 mm
10" × 14-1/4"
A5 57%
B5 70%
B6 50%
A3 115%
B5 A5 81%
182 × 257 mm
7-1/4" × 10"
A6 57%
B6 70%
A3 164%
A4 115%
B4 141%
B6 A6 81%
128 × 182 mm
5" × 7-1/4"
A4 164%
A5 115%
B4 200%
B5 141%
Inch Size
Original Size
Copy
Paper Size
Zoom Ratio
11" × 17" 11" × 14" 82%
279.4 × 431.8 mm
Legal 77%
Foolscap 76%
Letter 64%
Invoice 50%
11" × 15" 11" × 14" 93%
279.4 × 381 mm
Legal 77%
Foolscap 77%
Letter 73%
Invoice 50%
11" × 14" Legal 77%
279.4 × 355.6 mm
Foolscap 77%
Letter 77%
Invoice 50%
Legal Foolscap 92%
8-1/2" × 14"
Letter 78%
215.9 × 355.6 mm
Invoice 60%
11" × 17" 121%
Foolscap Letter 84%
8-1/2" × 13"
Invoice 64%
215.9 × 330.2 mm
11" × 17" 129%
11" × 14" 107%
Letter Invoice 64%
8-1/2" × 11"
11" × 17" 129%
215.9 × 279.4 mm
11" × 14" 127%
Invoice 11" × 17" 200%
5-1/2" × 8-1/2"
11" × 14" 164%
139.7 × 215.9 mm
Legal 154%
Foolscap 152%
Letter 129%
Zoom Ratio = Copy Paper Size
÷
Original Size
1" (inch) = 25.4 mm
1 mm = 0.0394 " (inch)
Chapter 3
Making Copies
2. Copying Procedure
39
