U-14 Default exposure mode/level
•
Determines the default exposure mode, either Auto or Manual, selected when
the control panel settings are reset.
If Auto is selected, this function also allows you to specify the default exposure
level (EXP) in the Manual Exposure Mode, after the Auto Exposure Mode has
been canceled.
If Manual is selected, the function also allows you to specify the default
exposure level (EXP) in the Manual Exposure Mode.
If any value between "0" and "8" is selected:
The Auto Exposure Mode is selected.
If any value between "10" and "18" is selected:
The Manual Exposure Mode is selected.
Auto Exposure Mode as Default
Setting
Value
Description Initial
Setting
Default Mode Exposure Setting in Manual Mode
0Auto Manual EXP1
1Auto Manual EXP2
2Auto Manual EXP3
3 Auto Manual EXP4
4Auto Manual EXP5 ✔
5Auto Manual EXP6
6Auto Manual EXP7
7Auto Manual EXP8
8Auto Manual EXP9
4. User’s Choice
Chapter 4
Auxiliary Functions
59
