Auto Size
1142O096CC
1142O096CC
Press the Auto Size Mode Key.
Selecting the Auto Size Mode
Auto Size Mode
•
The Auto Size Mode can be selected only when the copier is equipped with
an AF-3.
•
In the Auto Size Mode, the copier automatically selects the correct zoom ratio
according to the original size and copy paper size.
This mode is very helpful for neat filing when you need to make copies from
originals of assorted sizes.
Useful Tip
1142O046AA
%
50%~200%
1142O046AA
The Zoom Ratio Indicator shows
.
Paper
A4
1142O143DA
1142O143DA
Check the copy paper size.
➭
p. 33
If the desired paper size is not
loaded in the Drawer, load it into
the Drawer.
Add Paper Indicator
➭
p. 72
1
2
Chapter 3
Making Copies
2. Copying Procedure
37
