Types of Counters
•
Total Counter
:
Shows the total number of copies made since
the installation of the copier.
•
Size Counter
:
Shows the number of copies made on paper of
a size preset by the Technical Representative.
Counter Display
1. Checking the Total Number of Copies Mode
50%~200%
The Zoom Ratio Indicator
shows the upper 3 digits of
the count.
The Multi-Copy Display
shows the lower 2 digits
of the count.
Example: The count is 12,345 (copies).
1139O3790A
Meter Count
Toner
Drum Dehumidify
1142O152CA
1142O152CA
This function allows you to check the total
count of the two counters of the copier.
Chapter 4
Auxiliary Functions
52
