Konica Minolta EP1050 [125/131] Miscellaneous
![Konica Minolta EP1050 [125/131] Miscellaneous](/views2/1122092/page125/bg7d.png)
Control Panel
1142O084AA
Turn the Power Switch OFF.
Wipe the surface of the control
panel clean with a soft, dry cloth.
1
2
NEVER use a glass cleaner or any
other detergent to avoid damage
to the control panel keys.
NOTE
Front Door
1142O085AA
Swing down the Front Door.
Wipe the inside of the Front
Door clean with a soft cloth.
1
2
1. Care of the Copier
Chapter 8
Miscellaneous
113
