Chapter 6
Troubleshooting
This Chapter gives you instructions on how to troubleshoot copier
malfunctions.
1. When this Type of Copy is Produced
•
The Image is too light 96
•
The Image is too dark 96
•
The Copy is blurry 96
•
The Copy has lines 98
•
The Copy has dark specks or spots 98
•
The Edge of the Copy is dirty 98
•
The Image on the Copy is not aligned properly 98
2. The Copier is not functioning as designed
•
None of the Control Panel Indicators light up 100
•
Pressing the Start Key does not start the copy cycle 100
•
The Copier is not activated when the Power Switch is turned
ON 102
Chapter 6
Troubleshooting
95
