Action
The copier is in the Energy Saver Mode.
Press any Key on the Control Panel to cancel the Energy Saver Mode.
➭
p. 21
The copier is now warming up. Please wait.
➭
p. 19
Take the necessary steps for each Indicator.
➭
p. 68
The conditions for the copy mode which has been set are not met.
The number of copy sets to make in the Sort Mode exceeds 10.
Press the Clear key and reset the number of copy sets up to 10.
2. The Copier is not Functioning as Designed
Chapter 6
Troubleshooting
101
