Konica Minolta EP1050 [6/131] Chapter 6 troubleshooting 95
![Konica Minolta EP1050 [6/131] Chapter 6 troubleshooting 95](/views2/1122092/page6/bg6.png)
Chapter 6 Troubleshooting 95
1. When this Type of Copy is Produced
The Image is too light 96
The Image is too dark 96
The Copy is blurry 96
The Copy has lines 98
The Copy has dark specks or spots 98
The Edge of the Copy is dirty 98
The Image on the Copy is not aligned properly 98
2. The Copier is not functioning as designed
None of the Control Panel Indicators light up 100
Pressing the Start Key does not start the copy cycle
100
The Copier is not activated when the Power Switch is
turned ON 102
Chapter 7 Specifications 103
1. Copier EP1050 104
2. Automatic Document Feeder AF-3 106
3. 10 Bin Sorter S-104 107
4. Multi Bypass Table MB-1 108
Contents
vi
