Konica Minolta EP1050 [86/131] When an indicator lights up
![Konica Minolta EP1050 [86/131] When an indicator lights up](/views2/1122092/page86/bg56.png)
2. Detailed Instructions for Indicator Lights
Adding Paper (Multi Bypass Table)
1142O061AA
Monitor Display
1142O061AA
Add Paper Indicator
The indications on the left show that the
Multi Bypass Table has run out of paper.
1139O3910A
1139O1370A
Front Side
Unwrap the package of the copy
paper and fan the paper stack
thoroughly.
1
1139O6130A
Load the paper stack onto the
Table so that its front side (the
side facing up when the package
was unwrapped) faces up and
insert it into the copier as far as it
will go.
2
When using once-copied paper,
load the paper stack so that its
blank side faces up.
NOTE
Chapter 5
When an Indicator Lights Up
74
