U-13 Default auto exposure level
•
Determines the default exposure level in the Auto Exposure Mode.
Setting Value Description
Initial
Setting
46 Low, level 4
47 Low, level 3
48 Low, level 2
49 Low, level 1
50 Standard ✔
51 High, level 1
52 High, level 2
Lower
O
Higher
Level
4321Standard12
*
When the exposure level is "Low," the greater the level number is, the lower the
exposure level.
When the exposure level is "High," the greater the level number is, the higher
the exposure level.
4. User’s Choice
Chapter 4
Auxiliary Functions
58
