Konica Minolta EP1050 [20/131] System overview
![Konica Minolta EP1050 [20/131] System overview](/views2/1122092/page20/bg14.png)
The EP1050 system can be configured with the following
components.
◆
Automatic Document Feeder AF-3 <Option>
Permits automatic feeding of multiple
originals.
➭
p. 30.
AF-3
1139O0010A
S-104
1139O0020A
◆
10-Bin Sorter S-104 <Option>
Permits sorting or grouping
copies into up to 10 copy sets
or stacks.
➭
p. 44
1. System Overview
1142O010AA
EP1050
◆
EP1050
The Paper Drawer can hold up to 250 sheets of copy
paper (80 g/m
2
). The Manual Bypass Table allows
you to make a copy on paper which is not loaded in
the Drawer and which is fed into the copier manually
via this Table.
1139O0170A
◆
Multi Bypass Table
MB-1 <Option>
Holds up to 50 sheets of
standard paper which is
not loaded in any of the
Drawers, allowing to
make copies on them.
➭
p. 49
MB-1
Chapter 2
First Things to Know about your Copier
8
