Precautions for Handling
1139O6032A
•
Do not leave the I. U. in a bright
place.
1139O6042A
•
Do not store the I. U. in a hot place
of 40°C (104°F) or more.
1139O6052A
•
Do not store the I. U. in a humid
place or subject to water splash.
1139O6062A
•
Do not store the I. U. upside down
or tilted.
Do not subject the I. U. to vibration.
2. Detailed Instructions for Indicator Lights
Chapter 5
When an Indicator Lights Up
77
