Chapter 5
When an Indicator Lights Up
(Replenishing Supplies, Clearing Misfeeds,
and Correcting a Closure Failure)
This Chapter explains about the details of the various warning
indications given on the control panel, including those that entail
inhibition of the initiation of a copy cycle. It also shows action to be
taken for each case.
1. Quick Reference for Indicator Lights 68
2. Detailed Instructions for Indicator Lights
Add Toner Indicator 70
Add Paper Indicator 72
I.U. Service Life Indicator 76
Closure Failure Indicator 85
Misfeed Indicator
•
Misfeed Indicator and Monitor Display 86
•
Misfeed Clearing Procedure
: Copier EP1050 87
:
Automatic Document Feeder AF-3 90
:
Sorter S-104 92
Call-Tech.-Rep. Indicator 93
Chapter 5
When an Indicator Lights Up
67
