Turning ON and OFF
Turning Copier ON
Turning Copier OFF
..... Press the Power Switch to the " " position.
..... Press the Power Switch to the " " position.
1142O026AA
4. Turning ON and OFF, and Resetting the Copier
When Copier is Turned ON
Energy Saver
Panel Reset
1
4
7
3
6
9
C
2
5
8
0
Start Stop
About 1 minute
Blinking Orange Turns Green
A
100%
Meter Count
Toner
Drum Dehumidify
Paper
A4
%
50%~200%
Auto
Lighter Darker
Auto Size Sort Book
141% A4
A3
115% B4
A3
100% Full Size
81% B4 A4
70% A3 A4
1142O133DC
•
The Start Key blinks orange,
indicating that the copier is now
warming up.
•
In about 1 minute, the Start Key
turns green. Now the copier is ready
to make copies.
*
We call the settings established on
the control panel at this time the
"initial settings."
➭
p. 22
Chapter 2
First Things to Know about your Copier
19
