Konica Minolta EP1050 [50/131] Making copies

The copier has been factory-set to automatically select the Manual Mode. This

default setting can be changed to the Auto Size Mode by using the User’s

Choice.

NOTE

Initial mode

➭

p. 22

User’s Choice

➭

p. 57

Chapter 3

Making Copies

2. Copying Procedure
