Initial Mode and Panel Resetting
Initial Mode
When the Power Switch is turned ON, the initial settings are indicated on the
control panel.
* The initial settings serve as the reference for all control panel settings to be later
made.
The initial settings can be changed by User’s Choice. For details, see "USER’S
CHOICE,"
➭
p. 56
Useful Tip
A
100%
Meter Count
Toner
Drum Dehumidify
Paper
A4
%
50%~200%
Auto
Lighter Darker
Auto Size Sort Book
141% A4
A3
115% B4
A3
100% Full Size
81% B4 A4
70% A3 A4
1142O137DC
•
No. of copies to be made: 1
•
Zoom ratio: Full size (100%)
•
Auto Exposure Mode
•
Non-Sort Mode
Chapter 2
First Things to Know about your Copier
4. Turning ON and OFF, and Resetting the Copier
22
