U-15 Default Finishing mode
•
Determines the default finishing mode when the copier is equipped with the
Sorter.
Setting Value Description Initial Setting
0 Non-Sort ✔
1Sort
U-20 Auto Panel Reset ON/OFF
•
Selects whether to activate the Auto Panel Reset function 60 seconds after a
copy cycle has been completed or a control panel key has been pressed.
If "0" is selected:
The control panel settings remain valid even after 60 seconds.
If "1" is selected:
The control panel settings are canceled and the copier is reset into the
default mode after 60 seconds. (Auto Panel Reset)
Setting Value Description Initial Setting
0 Auto Panel Reset is not activated.
1 Auto Panel Reset is activated (after 1 minute) ✔
