Konica Minolta EP1050 [90/131] When an indicator lights up
![Konica Minolta EP1050 [90/131] When an indicator lights up](/views2/1122092/page90/bg5a.png)
Removing the I. U. from copier
1142O071AA
Swing down the Front Door.
Turn the Lock Release Lever
counterclockwise to swing up the
Upper Half of the copier.
1
1139O0520A
Turn the I. U. Lock Release
Lever and, while holding it
down, pull the I. U. halfway out
from the copier.
2
1139O0510A
Firmly grasp the I. U. with both
hands and pull it all the way out
of the copier.
3
2. Detailed Instructions for Indicator Lights
1142O072AA
Or
<If the copier is equipped with an
Automatic Document Feeder>
Unlock and swing up the Upper Half
of the copier. Then, lock the Stopper
M2
.
Chapter 5
When an Indicator Lights Up
78
