1139O3590A
Zoom Ratio
Meter Count
Toner
Drum Dehumidify
Paper
A4
%
50%~200%
Auto
Lighter Darker
Auto Size Sort Book
141% A4
A3
115% B4
A3
100% Full Size
81% B4 A4
70% A3 A4
1142O154DB
1142O154DB
The zoom ratio can be set manually by the operator when in the Manual Mode
or will be set automatically by the copier when in the Auto Size Mode. Select
the appropriate mode according to your needs.
The selected zoom ratio is shown on the Zoom Ratio Indicator.
100%
1142O142DC
141%
A4
A3
115% B4 A3
100% Full Size
81% B4 A4
70%
A3
A4
1142O142DB
Three reduction ratios (50%, 70%,
81%)
Three enlargement ratios (115%,
141%, 200%)
And Full Size (100%).
Types of Zoom Ratios
Fixed Zoom Ratios
50%~200%
1139O3590A
Any ratio from 50% to 200% (in 1%
increments) can be selected.
Zoom Ratios
Chapter 3
Making Copies
2. Copying Procedure
34
