1142O082AA
Housing Cover
Wipe the surface of the Housing
Cover clean with a soft cloth
dampened with neutral home
detergent.
Cleaning
1
2
Original Pad
1139O1830A
Raise the Original Cover.
Wipe the surface of the Original
Pad clean with a soft cloth
dampened with neutral home
detergent.
1
2
Original Glass
1142O083AA
Raise the Original Cover.
Wipe the surface of the Original
Glass clean with a soft, dry cloth.
1. Care of the Copier
Chapter 8
Miscellaneous
112
