Konica Minolta EP1050 [44/131] Making copies
![Konica Minolta EP1050 [44/131] Making copies](/views2/1122092/page44/bg2c.png)
1139O0920A
Original
Positioning Plate
Original Width Scale
Raise the AF-3 and place the
original face down on the
Original Glass. Align the rear left
corner of the original with the
marker on the Original Width
Scale. Then press the rear edge of
the original up against the
Original Positioning Plate at the
rear side of the Original Glass.
Gently lower the AF-3 and start
the copy cycle.
▼
1
2
For Originals Not Suitable for Reliable Operation of the AF-3
The AF-3 does not automatically eject an original manually placed on the
Original Glass. If you have two or more originals to make copies from, place
the originals on the Original Glass one by one.
NOTE
Chapter 3
Making Copies
2. Copying Procedure
32
