"Width" and "Length"
1139O1610A
When we talk about the size of the
original or copy, we call side A
"width" and side B "length."
A: Width
B: Length
Terms and Symbols Used
1139O1610A
<Lengthwise >
When the original or copy has a
"length" longer than its "width," we
call it "lengthwise" and use symbol
"L" or " ."
1139O1620A
<Crosswise >
When the original or copy has a
"length" shorter than its "width," we
call it "crosswise" and use symbol
"C" or " ."
Using This Manual
xi
