WDR-3124A Introduction
1-14
LED Indicators
The following table describes the LEDs on the front panel of the WDR-3124A.
LED Color State Description
Front Panel LET Indicators (System)
PWR1 Green On Power is being supplied from power input 1.
Off Power is not being supplied from power input 1.
PWR2 Green On Power is being supplied from power input 2.
Off Power is not being supplied from power input 2.
STATE Green On System startup is complete and the system is operating.
Blinking Device has been located by the Wireless Search Utility.
Off Power is off, or the system is booting up.
FAULT Red On System configuration error or a relay event has occurred.
Blinking (fast) IP address conflict (blinking interval: 0.5 sec).
Blinking (slow) Cannot get an IP address from the DHCP server
(blinking interval: 1 sec)
Off Power is off, or there is no error condition.
CELLULAR
SIGNAL
(3 LEDs)
Green On Number of LEDs to indicate cellular signal level when connected to a
cellular network with an IP address.
Signal LED 1: 0 < RSSI ≤ 12
Signal LED 2: 12 < RSSI ≤ 20
Signal LED 3: 20 < RSSI ≤ 31
WIFI
SIGNAL
(3 LEDs)
Green On/Off WiFi signal level (Client-Router mode only)
Signal LED 1: 0 < SNR ≤ 23
Signal LED 2: 23 < SNR ≤ 47
Signal LED 3: 47 < SNR
SIM1 Amber On/Off SIM 1 is active or inactive.
Blinking SIM 1 is not inserted or PIN code is incorrect.
SIM2 Amber On/Off SIM 2 is active or inactive.
Blinking SIM 2 is not inserted or PIN code is incorrect.
2G Amber On Registered to a base station with cellular connection in GPRS or EDGE
mode.
3G Amber On Registered to a base station with cellular connection in UMTS or HSPA
mode.
GPS Green On GPS has been located.
Blinking Locating GPS or fewer than four satellites have been located.
Off GPS has not been located.
LAN Port LED Indicators (Port Interface)
1000M Green On 1000Mbps link is active.
Blinking Data is being transmitted at 1000Mbps.
Off
1000Mbps link is inactive.
10/100M Amber On 10/100Mbps link is active.
Blinking Data is being transmitted at 10/100Mbps.
Off 10/100Mbps link is inactive.
