1. Introduction

The Moxa WDR-3124A industrial wireless device router is an ideal solution for hard-to-wire applications that

use mobile equipment connected over a wireless or cellular network. The WDR-3124A combines both IEEE

802.11n and cellular technologies to offer greater flexibility in implementing wireless networks. The

WDR-3124A is designed to operate at temperatures ranging from 0 to 55°C for standard models and -30 to

70°C for wide temperature models, and is rugged enough for any harsh industrial environment.

The following topics are covered in this chapter:



Overview



Package Checklist



Product Features



Product Specifications



Appearance



Device Dimensions



Connecting the Hardware

 Wiring Requirements



Installing a SIM Card



Device Mounting

 DIN-Rail Mounting

 Wall Mounting (optional)

 Grounding the WDR-3124A

 Wiring the Redundant Power Inputs

 Wiring the Relay Contact

 Wiring the Digital Inputs



Communication Connections

 10/100BaseT(X) Ethernet Port Connection

 1000BaseT Ethernet Port Connection

 Serial Connection



LED Indicators

 Beeper

 Reset Button
