WDR-3124A Web Console Configuration

3-37

The following figure shows the certificate generation and certificate export/import example.

Configuring X.509 Settings

NOTE

Before you configure X.509 settings, make sure that you have imported local and remote certificates in the

Local/Remote Certificate Upload

screen (click Advanced Settings > VPN > X.509 Certificate >

Local/Remote Certificate Upload

In the Tunnel Settings screen, select X.509 from the Authentication mode drop-down list and select a

certificate from the Local certificate and Remote certificate drop-down lists.

Device

1. Generate Root CA

2. Generate Local Certificate

3. Click PKCS#12 Export to export the local

certificate (local_CA_A.p12)

4. Click Certificate Export to export the

local certificate file (local_CA_A.pem)

5. Click VPN > X.509 >Local Certificate

Upload and import the local certificate

(local_CA_A.p12).

6. Click VPN > X.509 > Remote

Certificate Upload to import the remote

certificate (local_CA_B.pem).

1. Generate Root CA

2. Generate Local Certificate

3. Click PKCS#12 Export to export the

local certificate (local_CA_B.p12)

4. Click Certificate Export to export the

local certificate file (local_CA_B.pem)

5. Click VPN > X.509 >Local

Certificate Upload and import the

local certificate (local_CA_B.p12).

6. Click VPN > X.509 > Remote

Certificate Upload to import the

remote certificate (local_CA_A.pem).
