3. Web Console Configuration
The web console is the most user-friendly method available to configure the WDR-3124A. With a standard web
browser, you can easily access all settings and options. This chapter describes the configuration options and
screens in the web console. The same configuration options are also available through the Telnet and serial
consoles.
The following topics are covered in this chapter:
Accessing the Web Console
Overview
Basic Settings
Cellular Settings
Wireless Settings
Advanced Settings
Auto Warning Settings
Status
Maintenance
Save Configuration
Restart
Logout
