WDR-3124A Web Console Configuration

3-12

Service Forwarding

In AP mode, you can configure service forwarding to allow up to eight devices connected to the WDR-3124A to

connect to the OnCell Central server.

In the navigation panel, click Cellular Settings > OnCell Central Manager Settings > Service

Forwarding to display the configuration screen.

The following table describes the fields.

Field Description Default setting

Service forwarding Select Enable to allow up to eight Ethernet devices connected to the

WDR-3124A to connect to the OnCell Central server.

The system stores the device information in the Service Forwarding

Table.

Disable

Service forwarding

port

Enter the port number the WDR-3124A uses to establish a

connection from the Ethernet interface to the OnCell Central server.

63204

Act. Select this check box to enable the selected service forwarding rule.

To enable all entries, select the check box in the header.

Eth. Device Name Enter a descriptive name for the Ethernet device connected to the

WDR-3124A.

Eth. Device IP Enter the IP address of the Ethernet device connected to the

WDR-3124A.

Port Enter the service port number.

Description Enter a description for the service forwarding entry.

Wireless Settings

You can use the configuration screens under Wireless Settings to set wireless LAN settings and set up a wireless

network.

AP: In a wireless local area network (WLAN), an access point is a station that transmits and receives data from

WLAN-to-Cellular.

Client-Router: When the WDR-3124A is configured for Client-Router mode, it can be used as a LAN-to-LAN or

LAN-to-Cellular network adapter.
