WDR-3124A Web Console Configuration
3-42
For information on the event types, refer to the System Log Event Types section.
Syslog Server Settings
You can configure the parameters for your Syslog server on the Syslog Server Settings screen.
Field Description Factory Default
Syslog server 1/2/3 Enter the IP address of the 1st/ 2nd/ 3rd Syslog Server
Syslog port Enter the UDP port for the syslog server. 514
E-mail
E-mail Event Types
Select Active to enable the event types.
For information on the event types, refer to the System Log Event Types section.
