WDR-3124A Web Console Configuration

3-2

Accessing the Web Console

You can use a web browser to access the web console on the WDR-3124A. The web console is best viewed with

Microsoft

Internet Explorer 7.0 or 8.0 with JVM (Java Virtual Machine) installed.

1. Use either a straight-through or crossover Ethernet cable to connect the WDR-3124A to a computer.

2. Configure the IP address of the computer to be on the same subnet as the WDR-3124A.

For example, if the WDR-3124A is using the default IP address of 192.168.127.254 with a subnet mast of

255.255.255.0, set the IP address of the computer in the 192.168.127.xxx range.

NOTE

you reset the WDR-3124A to the factory default settings, the IP address will be reset to 192.168.127.254

3. Open a web browser on the computer and enter the IP address of the WDR-3124A in the address field. The

following figure shows an example.

4. The web console login page appears. Enter the user name (the default is admin) and password (the default

is root) and click Login.

NOTE

For security reasons, we strongly recommend

that you change the default password

(in the web console, click

Maintenance 

Password).

5. You may need to wait for a few moments for the web page to load on your computer.

Note that the model name and IP address of the WDR-3124A are shown in the title bar of the web page. You

can use this information to identify multiple WDR-3124A units on a network.
