WDR-3124A Introduction
1-2
Overview
The WDR-3124A industrial wireless device router supports both IEEE 802.11n and 3G cellular technologies to
meet the growing demand for flexible wireless solutions. The WDR-3124A is compliant with industrial
standards and approvals, covering operating temperature, power input voltage, surge, ESD and vibration. The
two redundant DC power inputs increase the reliability of the power supply and the dual-SIM support enables
redundant connections. In addition to establishing cellular connections, the WDR-3124A can be configured to
operate on either the 2.4 or 5 GHz bands and is backwards-compatible with existing 802.11a/b/g/n
deployments to future-proof your wireless investment.
Package Checklist
The WDR-3124A is shipped with the following items. If any of these items is missing or damaged, please
contact your customer service representative for assistance.
• WDR-3124A
• 1 GPS connector terminator
• 2 dual-band omni-directional antennas, 2 dBi, RP-SMA (male)
• 1 2G/3G omni-directional antennas, 2 dBi, SMA (male)
• 5 plastic RJ45 protective caps for serial console and Ethernet ports
• Quick installation guide (printed)
• Warranty card
NOTE
The above items
come with the standard WDR-3124A model, but the package contents may vary for
customized version
s.
Product Features
All WDR-3124A models include the following features:
• GSM/GPRS/EDGE/UMTS/HSPA cellular standards
• Five-band UMTS/HSPA 850/800/900/1900/2100 MHz
• Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz
• IEEE802.11a/b/g/n compliant
• Advanced wireless security
IEEE 802.11i support
SSID broadcast enable/disable
64-bit and 128-bit WEP encryption
WPA/WPA2-Personal and Enterprise (IEEE 802.1X/RADIUS and AES) 64-bit and 128-bit
WEP/WPA/WPA2
• DIN-rail or wall mounting (option)
• GuaranLink support for a reliable cellular connectivity
• OnCell Central Manager support for private IP communication and centralized management
• RJ-45 console management
• ABC-01 for configuration import/export
• IP30 protected high-strength metal housing
