WDR-3124A Web Console Configuration

3-26

Field Description Default setting

WLAN-to-Cellular

switchover

Specify the signal level threshold below which the WDR-

3124A uses

the WLAN interface as the default gateway.

WLAN SNR health

check duration

Enter the number of seconds the WDR-3124A is to check the SNR.

DHCP Server (AP mode)

DHCP (Dynamic Host Configuration Protocol) is a networking protocol that allows administrators to assign

temporary IP addresses to network computers by “leasing” an IP address to a DHCP client for a limited amount

of time, instead of assigning permanent IP addresses.

The WDR-3124A can act as a simplified DHCP server and assign IP addresses to DHCP clients by responding to

DHCP requests from clients. The IP-related parameters you set on this page will also be sent to the client.

You can also assign a static IP address to a specific client by entering its MAC address. You can configure up to

16 entries in the Static DHCP mapping list on the WDR-3124A.

NOTE

view IP address assignments, click Status > DHCP Client List.

The following table provides the field descriptions.

Field Description Default setting

DHCP server Select Enable to set the WDR-3124A as a DHCP server.

Select Disable to set the WDR-3124A as a DHCP client.

Disable

DNS relay Select Enable to set the WDR-3124A to redirect DNS requests

from DHCP clients to the DNS server specified.

Make sure that you specify the IP address of the

primary/secondary DNS server.

Disable

Default gateway Enter the IP address of the default gateway.

Subnet mask Enter the subnet mask to specify the type of network for the DHCP

clients.
