WDR-3124A Web Console Configuration

3-32

The following table includes the field descriptions.

Field Description Factory Default

Enable Select Enable to activate the port forwarding feature. Disable

Active Select this check box to activate the port forwarding entry.

Protocol Select an option from the drop-down list.

Public Port Enter the public port number.

Internal IP Enter th

e IP address of a LAN device to receive the redirected

traffic.

Internal Port Enter the port number on a LAN device to which to redirect

traffic.

Virtual Private Network

Computers that are part of a virtual private network (VPN) use a second, “virtual” IP address to connect to the

Internet. Instead of running across a single private network, some of the links between nodes that are part of

a VPN use open network connections or virtual circuits on a larger network, such as the Internet. With the help

of VPNs, cellular devices acting as a VPN client can initiate a connection with a VPN server. Once the connection

is established, cellular devices can communicate with other network devices on the same private network.

The following figure shows a network example.

WDR-3124A VPN Feature Overview

• The WDR-3124A IPSec provides security in a network with Gateway-to-gateway topology as illustrated in

the following figure.

• The WDR-3124A initiates a VPN connection to a VPN Server.

• The WDR-3124A IPSec operates in Tunnel mode with IPsec VPN tunnel.

 Manual Key/ESP, IKE/PSK

 DES/3DES/AES128/AES192/AES256 encryption

 MD5/SHA1 authentication

• IPsec NAT traversal and PFS (Perfect Forwarding Secrecy).
