2. Getting Started
When setting up the WDR-3124A for the first time, the first thing you should do is configure its IP address. This
chapter describes how to configure the IP address and describes the various configuration options.
The following topics are covered in this chapter:
Static and Dynamic IP Addresses
Factory Default IP Address
Configuration Options
Wireless Search Utility
Web Console
Telnet Console
SSH Console
Serial Console
