WDR-3124A Web Console Configuration

3-10

Field Description Default setting

Packet-level

connection check

retry count

Enter the number the WDR-3124A

is to try the connection check in

15 seconds before re-establishing the connection.

Transmission

connection check

If a remote system regularly monitors connection to the

WDR-3124A, select Enable to set the WDR-3124A to receive polling

information from the remote system at regular intervals.

If no polling information is received within the timeout period, the

WDR-3124A starts the GuaranLink recovery process.

Disable

Transmission

connection alive

check interval

Enter the time (between 1 to 600 minutes) the WDR-3124A is to

wait for polling information from a remote system before starting

the GuaranLink recovery process.

GPS Settings

Setting Description Factory Default

GPS Enable or disable the GPS function. Disable

A-GPS Enable or disable the A-GPS function. A-GPS will improve the

startup performance by downloading Almanac and/or

Ephemeris data if the cellular network can be accessed.

Disable

Report protocol Select TCP(client) or UDP protocol to configure the GPS data

report behavior.

TCP

Report to host Enter an IP or hostname to determine the GPS data report

server’s TCP or UDP port.

Report to period Use this option to specify how often the GPS data is

automatically reported.

Report format Select NMEA or General to configure the GPS data report

format. NEMA will report standard NEMA format. General will

report Latitude and Longitude format.

Nmea

Report ID Enter the lD to configure the GPS data report format header.

NEMA or Latitude/Longitude will add ID and MAC format.
