WDR-3124A Web Console Configuration
3-14
The following table provides the field descriptions.
Field Description Default setting
RF type Select an RF option from the drop-down list.
The following lists the options in the 2.4 GHz band:
• B – Sets the WDR-3124A to operate in IEEE 802.11b mode.
• G – Sets the WDR-3124A to operate in IEEE 802.11g mode.
• B/G Mixed – Sets the WDR-3124A to operate in IEEE 802.11b/
g
modes. In IEEE 802.11g mode, the WDR-3124A may operate at
a lower speed when IEEE 802.11b clients are on the network.
• G/N Mixed – Sets the WDR-3124A to operate in IEEE
802.11g/n modes. In IEEE 802.11n mode, the WDR-3124A may
operate at a lower speed when IEEE 802.11g clients are on the
network.
• B/G/N Mixed – Sets the WDR-3124A to operate in IEEE
802.11b/g/n modes. In IEEE 802.11g or IEEE 802.11n mode,
the WDR-3124A may operate at a lower speed when IEEE
802.11b clients are on the network.
• N Only (2.4 GHz) – Sets the WDR-3124A to operate in 2.4 GHz
IEEE 802.11n mode.
The following lists the options in the 5 GHz band:
• A – Sets the WDR-3124A to operate in IEEE 802.11a mode.
• A/N Mixed – Sets the WDR-3124A to operate in IEEE
802.11a/n
modes. In IEEE 802.11n mode, the WDR-3124A
may operate at
a lower speed when IEEE 802.11a clients are on the network.
• N Only (5 GHz) – Sets the WDR-3124A to operate in 5 GHz IEEE
802.11n mode.
Note: In legacy mode (802.11a/b/g), the WDR-
3124A receives and
transmits data only through antenna port A. To protect the
connectors and the RF module, all radio ports should be terminated
by either an antenna or a terminator. It is strongly recommended
that you use a resistive terminator to terminate an
unused antenna
port.
B/G/N Mixed
Channel
(For AP mode)
Select a wireless channel. The number of available channels varies
depending on the IEEE 802.11standard.
6 (in B/G/N Mixed
mode)
Channel width
(For IEEE 802.11n)
Select a channel width for wireless signals.
If you are not sure which option to use, select 20/40 MHz.
20 MHz
Channel bonding When you select 20/40 MHz in the Channel width field, the
system automatically sets the bonding channel based on the
channel setting.
SSID Enter an SSID (up to 31 characters).
Make sure that you enter the same SSID on an AP and wireless client
for them to communicate with each other.
SSID broadcast Select Enable to broadcast the SSID on the network.
Select Disable to hide the SSID.
Note: The WDR-3124A-JP (for Japanese frequency bands) only
connects SSID-hidden APs for IEEE 802.11a channels, and IEEE
802.11g/n channels 1 to 11. The WDR-3124A-EU (for European
frequency bands) only connects SSID-hidden APs for IEEE
802.11b/g/n channels.
Enable
