WDR-3124A Web Console Configuration
3-9
The following table provides the field descriptions.
Field Description Default setting
GuaranLink Select Enable to activate the GuaranLink feature.
For operator-level redundancy, enable GuaranLink with Dual SIM
mode to set the WDR-3124A to regularly check connection quality
and perform an automatic switchover in case a cellular connection is
down.
Select Disable to deactivate the GuaranLink feature.
Disable
Register to network
timeout
This field is used for ISP initial connection check.
Enter the time (10 – 600 minutes) the WDR-3124A is to wait before
terminating connection to an ISP and starts the GuaranLink
recovery process.
10
PPP retry count Enter the number of times (1-5) the WDR-3124A is to establish a
PPP connection to the ISP before restarting.
3
DNS/Ping remote
host 1/2
This field is used for packet-level and transmission connection
checks.
Enter the IP address or domain name of a remote host for Ping or
DNS lookup test.
ISP initial
connection check
Select Enable to set the WDR-3124A to complete the registration
process to a base station before the timeout specified in the
Register to network timeout field.
If the WDR-3124A fails to register to the base station within the
timeout period, it starts the GuaranLink recovery process.
Select Disable to allow the WDR-3124A to wait until base station
registration is successful.
Disable
Cellular connection
alive check
Depending on your ISP, cellular connection is terminated if there is
no active data transmission for a period of time.
Select Enable to set the WDR-3124A to keep the cellular connection
alive by performing a DNS lookup or remote host Ping if no data is
transmitted within the timeout period.
If the connection check fails after the number of retries specified in
the Cellular connection alive retry count field, the WDR-3124A
starts the GuaranLink recovery process.
Disable
Cellular connection
alive check interval
Enter the time (between 1 to 600 minutes) the WDR-3124A is to
wait before performing a connection check.
5
Cellular connection
alive check retry
count
Enter the number the WDR-3124A is to try the connection check i
n
15 seconds.
If the connection check fails, the WDR-3124A
starts the GuaranLink
recovery process.
5
Packet-level
connection check
Select Enable to check whether the cellular network is accessible
using DNS lookup and remote host ping, regardless of any existing
data transmission.
If the connection check fails after the number of retries specified in
the Packet-level connection check retry count field, the
WDR-3124A starts the GuaranLink recovery process.
Disable
Packet-level
connection check
action
Select one of the following options to determine if the connection
check is successful:
• DNS and Ping – Response from both the DNS server and
remote host.
• DNS or Ping – Response from either the DNS server or the
remote host.
DNS and Ping
Packet-level
connection check
interval
Enter the time (between 1 to 600 minutes) the WDR-3124A is to
wait before performing a connection check.
5
