WDR-3124A Web Console Configuration

The following table provides the field descriptions.

Field Description Default setting

Enable Select Enable to enable IP protocol filtering. Disable

Policy Select Accept to allow packets that meet the specified criteria.

Select Drop to deny packets that meet the specified criteria.

Drop

Source netmask

of source IP addresses.

Destination IP Enter the destination IP address to apply the IP protocol filter.

Destination

netmask

Enter the subnet mask to specify one destination IP address or a

range of destination IP addresses.

TCP/UDP Port Filter

The WDR-3124A’s TCP/UDP port filter is a policy-based filter that can allow or filter out TCP/UDP-based packets

with a specified source or destination port.

The WDR-3124A provides 32 entities for setting the range of source/destination ports of a specific protocol. In

port can be left empty if only a single port is specified. Of course, the end port cannot be larger then the start

The Application name is a text string that describes the corresponding entity with up to 31 characters.

Remember to check the Active check box for each entity to activate the setting.

Destination port Specify one or a range of destination ports.

Application name Enter a descriptive name for the service.
