VPN Settings
104
DWC-1000 Wireless Controller User’s Guide
Field
Description
SPI-Incoming
Enter a hexadecimal value from 3 and 8 characters. For example: 0x1234.
SPI-Outgoing
Enter a hexadecimal value from 3 and 8 characters. For example: 0x1234.
Encryption Algorithm
Select an algorithm to encrypt the data.
Key Length
If Encryption Algorithm = BLOWFISH or CAST12, enter a key length.
For BLOWFISH, the Key Length must be a value between 40 and 448, and a multiple of 8.
For CAST128, the Key Length must be a value between 40 and 128, and a multiple of 8.
Key-In
Enter the encryption key of the inbound policy. The length of the key depends on the algorithm
chosen:
DES = 8 characters
3DES = 24 characters
AES=128 = 16 characters
AES=192 = 24 characters
AES=256 = 32 characters
AES=CCM = 16 characters
AES=GCM = 20 characters
TWOFISH (128) = 16 characters
TWOFISH (192) = 24 characters
TWOFISH (256) = 32 characters
BLOWFISH and CAST128 are variable length algorithms
Key-Out
Enter the encryption key of the outbound policy. The length of the key depends on the algorithm
chosen, as shown for Key-In.
Integrity Algorithm
Select the algorithm used to verify the integrity of the data. Choices are:
SHA-1
SHA-224
SHA-256
SHA-384
SHA-512
MD5
Key-In
Enter the integrity key (for ESP with Integrity-mode) for the inbound policy. The length of the key
depends on the algorithm chosen:
MD5 = 16 characters
SHA=1 = 20 characters
SHA2=224 = 28 characters
SHA2=256 = 32 characters
SHA2=384 = 48 characters
SHA2=512 = 64 characters
Key-Out
Enter the integrity key (for ESP with Integrity-mode) for the outbound policy. The length of the
key depends on the algorithm chosen, as shown for Key-In.
Phase 2 (Auto Policy Parameters)
