D-Link DWC-1000 [182/246] Controller associated client status

Viewing Status and Statistics

182

DWC-1000 Wireless Controller User’s Guide

Controller Associated Client Status

Path: STATUS > Wireless Client Info > Associated Clients > Controller Status

The CONTROLLER ASSOCIATED CLIENT STATUS page shows information about the

controller that manages the access point to which the client is associated.

Table 7-36. Fields on the CONTROLLER ASSOCIATED CLIENT STATUS Page

Field

Description

Controller IP Address

IP address of the controller that manages the access point to which the client is associated.

Client MAC Address

MAC address of the associated client.
