Viewing Status and Statistics
134
DWC-1000 Wireless Controller User’s Guide
Table 7-2. Fields on the WIRELESS LAN AP INFORMATION Page
Field
Description
MAC Address (*) Peer Managed
Ethernet address of the managed access point. If an asterisk (*) follows the MAC address, the
access point is managed by a peer controller.
IP Address
Network IP address of the managed access point.
Age
Time since last communication occurred between the wireless controller and the access point.
Status
Current managed state of the access point. Possible values are:
Discovered = access point is discovered by the wireless controller, but not authenticated.
Authenticated = access point has been validated and authenticated (if authentication is
enabled), but it is not configured.
Managed = profile configuration has been applied to the access point and the access point is
operating in managed mode.
Failed = wireless controller lost contact with the access point. A failed entry remains in the
Managed AP database, unless you remove it. Note that a managed access point shows a
failed status temporarily during a reset.
If management connectivity is lost for a managed access point, both of its radios are turned down
and all clients associated with the access point are disassociated. The radios resume operation
when that access point is managed again by a wireless controller.
Profile
Configuration profile applied to the managed access point. The profile is assigned to the access
point in the Valid AP database.
Radio Interface
Wireless radio mode that each radio on the access point is using.
Table 7-3. Buttons on the WIRELESS LAN AP INFORMATION Page
Button
Description
View AP Details
Shows detailed status information collected from the access point.
View Radio Details
Shows detailed status for a radio interface.
View Neighbor APs
Shows the neighbor APs that the specified AP has discovered through periodic RF scans on the
selected radio interface.
View Neighbor Clients
Shows information about wireless clients associated with an access point or detected by the
access point radio.
View VAP Details
Shows summary information about the virtual access points (VAPs) for the selected access point
and the access point radio interface that the wireless controller manages.
View Distributed Tunnelling Details
Shows information about the L2 tunnels currently in use on the access point.
