Troubleshooting
224
DWC-1000 Wireless Controller User’s Guide
For each facility, the following events (in order of severity) can be logged:
Severity
Description
Emergency
System is unusable
Alert
Action must be taken immediately
Critical
Critical conditions
Error
Error conditions
Warning
Warning conditions
Notification
Normal but significant condition
Information
Informational
Debugging
Debug-level messages
The display for logging can be customized based on whether the logs are sent to the Event
Log viewer in the web management interface (the Event Log viewer is in the Status > Logs
> View All Logs) or a remote Syslog server for later review. E-mail logs, discussed in a
subsequent section, follow the same configuration as logs configured for a Syslog server.
