Securing Your Network
94
DWC-1000 Wireless Controller User’s Guide
Additional Security Settings
The wireless controller provides more security settings than those covered in this chapter.
The following table describes these settings. For more information, go to the page in the web
management interface and then access the wireless controller online help in the Helpful
Hints area (see Figure 3-1 on page 32).
Note: Asterisks in the table below indicate settings that require a DWC-1000-VPN-LIC
License Pack.
Security Setting
Path
Attack checks*
ADVANCED > Advanced Network > Attack Checks
Certificates
ADVANCED > Certificates
Firewall settings
Default outbound policy
Firewall rules
Custom services
ALGs
SMTP ALG
ADVANCED > Firewall Settings
ADVANCED > Firewall Settings > Default Outbound Policy
ADVANCED > Firewall Settings > Firewall Rules
ADVANCED > Firewall Settings > Custom Services
ADVANCED > Firewall Settings > ALGs
ADVANCED > Firewall Settings > SMTP ALG > SMTP ALG
Configuration
ADVANCED > Firewall Settings > SMTP ALG > Approved
Mail Ids
ADVANCED > Firewall Settings > SMTP ALG > Blocked Mail
Ids
ADVANCED > Firewall Settings > SMTP ALG > Subject list
Intel AMT*
ADVANCED > Intel AMT
RADIUS settings
ADVANCED > Radius Settings
USB device status
SETUP > USB Settings > USB Status
USB port sharing
SETUP > USB Settings > USB Share Port
