D-Link DWC-1000 [180/246] Associated client vap status

Viewing Status and Statistics

180

DWC-1000 Wireless Controller User’s Guide

Associated Client VAP Status

Path: STATUS > Wireless Client Info > Associated Clients > VAP Status

Each AP has 16 virtual access points (VAPs) per radio, and every VAP has a unique MAC

address (BSSID). The VAP ASSOCIATED CLIENT STATUS page shows information about

the VAPs on the managed access point that have associated wireless clients. To disconnect

a client from an access point, check the box next to the BSSID and click Disassociate.
