D-Link DWC-1000 [82/246] Securing your network

DWC-1000 Wireless Controller User’s Guide

5. SECURING YOUR NETWORK

The wireless controller supports a number of features for securing your network. This

chapter describes the following commonly used security features:

 Managing Clients (page 83)

 Content Filtering (page 88)

For information about additional security settings not described in this chapter, see

―Additional Security Settings‖ on page 94.

Note: The procedures in this chapter should only be performed by expert users who

understand networking concepts and terminology.
