Advanced Configuration Settings
80
DWC-1000 Wireless Controller User’s Guide
Additional Advanced Configuration Settings
The wireless controller provides more advanced configuration settings than covered in this
chapter. The following table describes these settings. For more information, go to the page
in the web management interface and then access the wireless controller online help in the
Helpful Hints area (see Figure 3-1 on page 32).
Note: Asterisks in the table below indicate advanced configuration settings that require a
DWC-1000-VPN-LIC License Pack.
Advanced Configuration Setting
Path
Advertisement prefixes
ADVANCED > IPv6 > IPv6 LAN > Advertisement Prefixes
Application rules*
ADVANCED > Application Rules > Application Rules
Application rules status*
ADVANCED > Application Rules > Application Rules Status
Auto VOIP
SETUP > QoS > LAN QoS > Auto VOIP
Configuration items
ADVANCED > Peer Controllers > Configuration Items
Configuration request status
ADVANCED > Peer Controllers > Configuration Request Status
Date and Time
TOOLS > Date and Time
DHCP v6 leased clients
ADVANCED > IPv6 > IPv6 LAN > DHCPv6 Leased Clients
Distributed tunneling
ADVANCED > Global > Distributed Tunneling
DMZ DHCP reserved leased clients
SETUP > DMZ Setup > DMZ DHCP Leased Clients
DMZ DHCP reserved IPs
SETUP > DMZ Setup > DMZ DHCP Reserved IPs
Double VLANs
SETUP > VLAN Settings > Double VLAN
Firmware via USB
TOOLS > Firmware via USB
Flow control
SETUP > QoS > LAN QoS > Flow Control
Get user database to the router
ADVANCED > Users > Get Users DB
GVRP
SETUP > GVRP
IGMP
ADVANCED > Advanced Network > IGMP Setup
IP aliasing*
SETUP > Internet Settings > IP Aliasing
IP/MAC binding
ADVANCED > IP/MAC Binding
IP mode
ADVANCED > IPv6 > IP Mode
IP option configuration
ADVANCED > IPv6 > IP Config
IP v6 LAN configuration
ADVANCED > IPv6 > IPv6 LAN > IPv6 LAN Config
IP v6 options*
ADVANCED > IPv6 > IPv6 LAN > IPv6 Option 1 Config
ADVANCED > IPv6 > IPv6 LAN > IPv6 Option 2 Config
