Viewing Status and Statistics
186
DWC-1000 Wireless Controller User’s Guide
Pre-Authorization History
Path: STATUS > Wireless Client Info > Pre-Auth History
To help authenticated clients roam without losing sessions and needing to re-authenticate,
wireless clients can try to authenticate to other access points within range of the client. For
successful pre-authentication, the target access point must have a VAP with an SSID and
security configuration that match the client, including MAC authentication, encryption
method, and pre-shared key or RADIUS parameters. The access point that the client is
associated with captures all pre-authentication requests and sends them to the controller.
The DETECTED CLIENT PRE-AUTHENTICATION HISTORY SUMMARY page shows
detected clients that have made pre-authentication requests and identifies the access points
that received the requests.
Table 7-40. Fields on the DETECTED CLIENT PRE-AUTHENTICATION HISTORY
SUMMARY Page
Field
Description
MAC Address
MAC address of the client.
AP MAC Address
MAC address of the managed access point to which the client has pre-authenticated.
Radio Interface Number
Radio number to which the client is authenticated (Radio 1 or Radio 2).
VAP MAC Address
VAP MAC address to which the client roamed.
SSID
SSID name used by the VAP.
Age
Time since the history entry was added.
User Name
User name of client that authenticated via 802.1X.
Pre-Authorization Status
Indicates whether the client successfully authenticated. Shows a status of Success or Failure.
Table 7-41. Button on the DETECTED CLIENT STATUS Page
Field
Description
Refresh
Updates the information on the page.
