Viewing Status and Statistics
143
DWC-1000 Wireless Controller User’s Guide
Table 7-7. Fields on the ASSOCIATED CLIENTS STATISTICS Page
Field
Description
Packets Received
Total number of packets received from the client station.
Bytes Received
Total number of bytes received from the client station.
Packets Transmitted
Total number of packets transmitted to the client station.
Bytes Transmitted
Total number of bytes transmitted to the client station.
Packets Receive Dropped
Number of packets received from the client station that were dropped.
Bytes Receive Dropped
Number of bytes received from the client station that were dropped.
Packets Transmit Dropped
Number of packets transmitted to the client station that were dropped.
Bytes Transmit Dropped
Number of bytes transmitted to the client station that were dropped.
Fragments Received
Total number of fragmented packets received from the client station.
Fragments Transmitted
Total number of fragmented packets transmitted to the client station.
Transmit Retries
Number of times transmits to client station succeeded after one or more retries.
Transmit Retries Failed
Number of times transmits to client station failed after one or more retries.
TS Violate Packets Received
Count of packets received by an access point from a wireless client for the specified access
category.
TS Violate Packets Transmitted
Count of packets transmitted by an access point to a wireless client for the specified access
category.
Duplicates Received
Total number of duplicate packets received from the client station.
Table 7-8. Buttons on the ASSOCIATED CLIENTS STATISTICS Page
Field
Description
Refresh
Updates the information shown on the page.
View Details
Shows detailed status associated client.
