D-Link DWC-1000 [44/246] Add captive portal users

Basic Configuration

DWC-1000 Wireless Controller User’s Guide

c. Complete the fields in Table 3-6 and click Save Settings.

Table 3-6. Captive Portal Settings

Field

Description

Group Configuration

Group Name

Enter a name for the group.

Description

Enter a description of the group.

User Type

Captive Portal User

Check this box.

2. Add captive portal users

a. Click ADVANCED > Users > Users. The USERS page appears.
