VPN Settings

111

DWC-1000 Wireless Controller User’s Guide

Deleting IPsec Policies

Path: SETUP > VPN Settings > IPsec > IPsec Policies

If you no longer need an IPsec policy, you can delete it.

Note: A precautionary message does not appear before you delete an IPsec policy.

Therefore, be sure you do not need an IPsec before you delete it.

1. Click SETUP > VPN Settings > IPsec > IPsec Policies. The IPSEC POLICIES page

appears.

2. Under List of VPN Policies, check the IPsec auto policy or manual policy you want to

delete and click Delete.
